Marine Plywood

Marine Plywood
Marine Plywood
Product Code : IS-710
Brand Name : BHUTAN TUFF
Product Description

Decorative Marine Plywood

It is maintained from selected timbers bonded with high quality resorcinol phenol Formaldehyde resin. It is pressed under proper temperature and high pressure and treated in a vacuum pressure impregnation plant with specific preservatives as per IS5539: 1969. Bhutan Tuff Marine Plywood can withstand unfavorable climatic conditions, alternate drying and wetting. Moreover, it is safe against marine organisms and wood borers. Bhutan tuff Marine Plywood can withstand 108 hrs. Boiling at 100oC temperature with out showing any signs of veneers separation/de-lamination.

Applications

Maintenance and repair of Marine and river crafts, interior of ships and liners, heat exchanger, cooling tower, public hoarding, signboards, display boards, etc, tanks for liquid chemicals, portable cabins and shelters that are exposed to severe conditions, structural applications.

Technical Specifications

S.No. Test

I.S.I requirement

Test results

Moisture content

5-15%

7.5%

Glue shear strength in dry condition

Individual
Average Min.
1100 Newton
1350 Newton
1400 Newton
1590 Newton

Glue shear strength in wet condition

Individual
Average Min.
800 Newton
1000 Newton
1080 Newton
1360 Newton

Glue shear strength in Mycological test

Individual
Average Min.
800 Newton
1000 Newton
1090 Newton
1350 Newton
Tensile strength
Parallel to grain direction
Right angle to grain direction
Sum of both directions


42.0N/mm2
25.0N/mm2
84.5N/mm2


645 KN/m2
395 KN/m2
1040 KN/m2
MOR N/mm2
Parallel to grain
Perpendicular to grain
Avg./Min
50/45
30/27


60/55
40/35
MOE N/mm2
Parallel to grain
Perpendicular to grain
Avg./Min
7500/6700
4000/3600


8000/7500
4500/4000
